Nordic

Nordic / Freudenberg 3 Lug Filter

Type: Dust Filter

Shape: Cylindrical

Fitting: 3 & 4 Lugged

Here at Cavendish Filters, we manufacture 3 lug filters in a range of sizes:- 145mm PCD, 150mm PCD, 225mm PCD. 370mm PCD and 397mm PCD. We have a range of materials available including Aluminium, ABS Plastic and Resin. All Lengths available up to 1400mml (longer possible, please see “Additional Services”). Medias include:-  Cellulose blend 80/20 FR, STD Polyester, A/Static Polyester.

Buy Our 3 Lug Equivalents With Confidence

  • We make all of our filters by hand at our factory in Leicester, United Kingdom
  • Our  3 Lug filters are made using high quality Spunbonded Polyester media that lasts considerably longer than traditional media
  • We have 30 years of experience, exporting our products to businesses worldwide
  • We can manufacture bespoke filters to fit any criteria. If you can’t find what you are looking for, please click here to request a quote or more information.

Medias & Applications

Filter Manufacture

Polyester, Anti Static, Cellulose Blends, Nano and other coatings.

Applications :- A few suggestions

  • Carbon Impregnated 80/20 Cellulose/Polyester FR: A new introduction to our range of medias. This media can be used on a number of ATEX applications, with the benefit of increased surface area, to our Anti Static Polyester range. This allows Dust Collectors to cope better with heavy dust loads, whilst allowing manufacturers to install smaller  Dust Collector Units on new installations.
    This media is ideal for applications with  an explosion risk, such as :- Stainless Steel Blasting, Wood Cutting, Waste Recycling, Powder Coating, to name a few.

    Carbon Impregnated 80/20FR

  • 80/20FR :- Performs well on fine dust and some less abrasive dust. High Filtration Efficiency with Flame Retardant coating, Uses :- Pharmaceutical, Grinding, Powder Coating.
  • NanoFR.:- Premium Performance on extra Fine dust and fume. Ideal for Very fine Particulate, With Flame Retardant Coating Uses:- Welding Fume,  Plasma/ Laser Cutting.
  • STD Polyester 260g :- Wide pleat spacing, Excellent particle release, Uses:- Cement dust, Sand Blasting dust, Ceramic dust.
  • Anti Static Polyester 260g:- As above but Aluminium Coating, Uses:- S Wood Dust, Zinc Dust and other combustible dust.
  • PTFE Coat/Membrane, available on Polyester :- A Hydrophobic (Water repellent) Coating/Membrane, Uses :- Milk Powder, Sugar or other fine/and or sticky dust.
  • Other finishes/coatings available to suit most applications. Please contact us for more information.

Made To Order

We can manufacture bespoke dust filters to fit any criteria. If you can’t find what you are looking for, just fill in the contact form at the foot off the page.

Export & Shipping

We have 30 year of experience, exporting our products to businesses around the world.

Customers within Singapore, Malaysia and The Philippines should contact our Agents Intair Asia.

Lead Times

We can turn around cartridge orders faster than many large manufacturers. Our flexible production facilities allow us to get your filters to you quickly.

Made In The UK

We make all of our filters by hand at our factory in Leicester, United Kingdom.
